Home ＞ Sensor Solutions ＞ Toilet System ＞ EJ-P0023 Touchless Automatic Urinal Flush System
EJ-P0023 Touchless Automatic Urinal Flush System
    Publish time 2020-06-13 20:25
Automatic Sensor Circuit
EJ-P0023 Touchless Automatic Urinal Flush System


Applications
PEPE produces sensors and control units for OEM manufacturers of electronic faucets & toilets, and home appliances.

Applications:
Water control applications
Water dispensers
Automatic flushing
Power management

Product Description

OEM Touchless Automatic Urinal Flush System


With stable performance in indoor and outdoor environments Available sensor covers and connectors in different shapes Optional operating modes and outputs for specific applications.

Available operating modes are controlled via sensors or buttons.




Model number:
EJ-P0023
Technology: Active Infrared
Power supply mode:
DC 4.5V-6.6V
Detection range default setting for different applications: (adjustable)
Water sensor: 5-300 mm  400-850 mm
Smart home: 0-900 mm
Response time:
1 S
Stand-by consumption:
 <20 uA
Maximum output current:
800mA
Low voltage alarm:
< 4.5 V
Signal pulse:
45 ms  (adjustable)
Ingress protection:IP 67
Directive:
2014/35/EU, 2014/30/EU， FCC PART 15B
